Product introduction
Our cold room panels are crafted using a blend of polyisocyanate and polyether or polyester polyol, resulting in a high-performance product that's perfect for cold storage. The panels are known for their superior heat conductivity and temperature preservation, as well as impressive compressive and tensile strength, preventing deformation and ensuring long-lasting performance.
Our cold room panels are available in three thicknesses: 100-120mm for cold storage insulation, 150-200mm for freezer insulation, and 200-250mm for quick-freezer insulation. No matter which thickness you choose, you'll enjoy a reliable and efficient product that's ideal for maintaining the temperature of your cold storage.Heat and sound insulation. Temperature suitable for PU ranges from -200 centigrade to 150 centigrade.Good chemical resistance, waterproof, anti-corrosion, insect-free etc.Energy conservation, environmental protection, economical, heat insulting, good structure, easy-doing construction
advantage and applications
PU cold storage room panel is a kind of board used for enclosing structures, which has good heat insulation and higher intensity.
It can reduce the heat transmission caused by difference in the internal and external temperature, and get to maximum efficiency of freezing and refrigeration systems.
Heat insulation material for lower construction cost. Panels are in multiple varieties and specifications to meet the need of various sites and projects.
It can be widely used as the structural material and heatproof material in petroleum industry, chemical industry, construction, packing, refrigeration, military industry, space industry, aviation, transportation, industrial model design and so on.
specification
| Effective width | 1000(mm) |
| Length | According to customer's request, less than 11.8m. |
| Materials | Polyurethane foam panel,Color steel tile |
| Structure | Upper and lower layer: Color steel sheet |
| Middle: Polystyrene foam board |
| Density | 40-45 kg/m³ |
| Conventional color | White, sea blue, red etc. |
| Life time | More than 20 Years |
| Performance | Light weight, heat insulation, water resistant, green and environmental |
| Usage | Roof, Wall, Ceiling, Partition |
