Customizable PU Roof Panel Fireproof Sandwich Roof Panel For Sound Insulation

Henan Zengtuo Industrial Co., LTD
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Customizable PU Roof Panel Fireproof Sandwich Roof Panel For Sound Insulation

Place of Origin : Henan, China

Brand Name : ZENGTUO

Supply Ability : 4000 Ton/Tons per Month

MOQ : 500 square meters

Price : $8.90/square meters 500-999 square meters

Color : White, Grey, Blue, Red, Green

Sound Insulation : 40dB

Load Bearing Capacity : Up to 150kg/m2

Installation Method : Concealed fixing or Exposed fixing

Panel Length : Customizable

Core Thickness : 50mm, 75mm, 100mm, 120mm, 150mm

Material : Polyurethane foam

Panel Width : 1000mm

Surface Material : Color steel sheet, Aluminum sheet, Stainless steel sheet

Water Absorption : Less than 1%

Application : Roofing for industrial and commercial buildings

Thermal Conductivity : 0.023 W/mK

Panel Thickness : 0.4mm - 0.8mm

Contact Now


Features

Quickly build: Polyurethane panel is produced under the high temperature control of the factory and in a constant temperature environment, the quality is stable;



High structural rigidity and reliability.



Corrosion resistance

The inner plate can use aluminum foil instead of color steel plate to improve the product's high temperature and corrosion resistance.



High structural rigidity and reliability.



advantage



Strong and durable

Polyurethane four-wave roof plate is made of double-sided composite aluminum-zinc plated color steel, supplemented by hard hair on both sides of the groove



Excellent fire performance, polyurethane materials can meet the high fire performance requirements of building insulation materials, effectively prevent the spread of fire, that is, B1 or B2 flame retardant standards.

The insulation performance of polyurethane plate is better. The insulation performance of pure polyurethane is higher than that of polyurethane edge sealing, and the fire performance of polyurethane edge sealing is higher than that of pure polyurethane composite board



PU Panel roofing or what we call insulated panels. we have Roofing PU Panel ,These panels consist of a rigid foam insulation layer sandwiched between two structural metal skin surfaces. The core consists of Polyurethane and Polyisocyanurate insulated panels that form a strong bond to the outer skin, creating a durable panel.



Our PU roof panels are structurally superior to traditional wood framing as they are stronger and less susceptible to shifting. They are extremely durable, which is important in roofing as roofs are expected to protect a structure and the people inside it from external threats such as bad weather. Though lightweight, it is important to note that PU panels can be as strong as a rock, making them a Well-Recommended Roofing Material for homes or commercial structures.







specification

Type

PU sandwich roof panel/polyurethane sandwich roof panel

Core

polyurethane

Density

40-45kg/m3

Surface material

color steel sheet/aluminum foil

Steel thickness

0.3-0.8mm

Core thickness

40/50/75/90/100/120/150/200mm

Length

1-11.8m

Effective Width

1000mm

Fire Rating

Great B

Color

Any Ral color

Wave

four waves

Advantages

Lightweight/Fireproof/Waterproof/Easy Install/Insulation

Surface Appearance

seamless-wave/slitwidth-wave/concave-wave/Flat/Embossed/Other

Usage

It is suitable for the various roofs referring to the large-size factory buildings, storage, exhibition halls, gymnasiums, freezing stores, purification workshops, etc.
